pUG-303
(Plasmid
#104732)
-
PurposeLevel 2 construct
-
Depositing Lab
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 104732 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepET-28GG
- Backbone size w/o insert (bp) 5190
-
Vector typeBacterial Expression
Growth in Bacteria
-
Bacterial Resistance(s)Kanamycin, 50 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberLow Copy
Gene/Insert
-
Gene/Insert nameHIS-Ubq_UBA1_HA-UBC12_EL3
-
Alt nameAT4G05320,AT2G30110,AT3G08700
-
SpeciesA. thaliana (mustard weed)
-
Insert Size (bp)4342
- Promoter T7
-
Tag
/ Fusion Protein
- HIS-Ubq, HA-E2 (N terminal on insert)
Cloning Information
- Cloning method Restriction Enzyme
- 5′ cloning site BpiI (destroyed during cloning)
- 3′ cloning site BpiI (destroyed during cloning)
- 5′ sequencing primer T7
- 3′ sequencing primer T7 Terminal (Common Sequencing Primers)
Resource Information
-
Addgene Notes
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pUG-303 was a gift from Marco Trujillo (Addgene plasmid # 104732 ; http://n2t.net/addgene:104732 ; RRID:Addgene_104732) -
For your References section:
UbiGate: a synthetic biology toolbox to analyse ubiquitination. Kowarschik K, Hoehenwarter W, Marillonnet S, Trujillo M. New Phytol. 2018 Mar;217(4):1749-1763. doi: 10.1111/nph.14900. Epub 2017 Nov 30. 10.1111/nph.14900 PubMed 29194629
