pEB2-2ndVal mCherry2-L
(Plasmid
#104027)
-
PurposePlasmid encoding 2ndVal mCherry2-L
-
Depositing Lab
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 104027 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepEB2
- Backbone size w/o insert (bp) 3224
- Total vector size (bp) 3935
-
Modifications to backboneSee "Notes On Plasmids In This Collection"
-
Vector typeBacterial Expression ; Low copy
Growth in Bacteria
-
Bacterial Resistance(s)Kanamycin, 50 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)MG1655
-
Copy numberLow Copy
Gene/Insert
-
Gene/Insert name2ndVal mCherry2-L
-
SpeciesSynthetic
-
Insert Size (bp)711
-
MutationmCherry2-L with valine inserted in 2nd position
- Promoter proC
Cloning Information
- Cloning method Gibson Cloning
- 5′ sequencing primer GCGTATCACGAGGCCCTTTC
- 3′ sequencing primer AAAGGGAAAACTGTCCATATGCAC (Common Sequencing Primers)
Resource Information
-
Supplemental Documents
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
Depositor Comments
This is a version of mCherry2-L with a valine inserted in the second position. Please see "Notes On Plasmids In This Collection" document for further details and references.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pEB2-2ndVal mCherry2-L was a gift from Philippe Cluzel (Addgene plasmid # 104027 ; http://n2t.net/addgene:104027 ; RRID:Addgene_104027) -
For your References section:
Systematic characterization of maturation time of fluorescent proteins in living cells. Balleza E, Kim JM, Cluzel P. Nat Methods. 2018 Jan;15(1):47-51. doi: 10.1038/nmeth.4509. Epub 2017 Nov 20. 10.1038/nmeth.4509 PubMed 29320486
