pUDE731
(Plasmid
#103008)
-
PurposeS. cerevisiae Episomal plasmid harboring Fncpf1 under the control of TDH3p
-
Depositing Lab
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 103008 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepMEL10
-
Backbone manufacturerMans, R. et al (2015) CRISPR/Cas9: a molecular Swiss army knife FEMS Yeast Res 15
- Backbone size w/o insert (bp) 5658
- Total vector size (bp) 9695
-
Vector typeYeast Expression
-
Selectable markersURA3
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert nameFncpf1
-
SpeciesFrancisella tularensis subsp. novicida U112
-
Insert Size (bp)4038
-
Mutationhuman codon optimized
-
GenBank IDCP000439.1 CP000439.1
- Promoter TEF1
-
Tags
/ Fusion Proteins
- NLS (C terminal on insert)
- 3HA (C terminal on insert)
Cloning Information
- Cloning method Gibson Cloning
- 5′ sequencing primer GCCTACGGTTCCCGAAGTATGCTGCTGATGTCTGGCTATACCTATCCGTCTACGTGAATACCCTCACTAAAGGGAACAAAAG
- 3′ sequencing primer GTTGAACATTCTTAGGCTGGTCGAATCATTTAGACACGGGCATCGTCCTCTCGAAAGGTGGGCCGCAAATTAAAGCCTTCGAG (Common Sequencing Primers)
Resource Information
-
A portion of this plasmid was derived from a plasmid made byAddgene plasmid # 69976--Cpf1 Is a Single RNA-Guided Endonuclease of a Class 2 CRISPR-Cas System. Zetsche B, Gootenberg JS, Abudayyeh OO, Slaymaker IM, Makarova KS, Essletzbichler P, Volz SE, Joung J, van der Oost J, Regev A, Koonin EV, Zhang F. Cell. 2015 Sep 23. pii: S0092-8674(15)01200-3. doi: 10.1016/j.cell.2015.09.038. 10.1016/j.cell.2015.09.038 PubMed 26422227
-
Articles Citing this Plasmid
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pUDE731 was a gift from Jean-Marc Daran (Addgene plasmid # 103008 ; http://n2t.net/addgene:103008 ; RRID:Addgene_103008) -
For your References section:
FnCpf1: a novel and efficient genome editing tool for Saccharomyces cerevisiae. Swiat MA, Dashko S, den Ridder M, Wijsman M, van der Oost J, Daran JM, Daran-Lapujade P. Nucleic Acids Res. 2017 Dec 1;45(21):12585-12598. doi: 10.1093/nar/gkx1007. 10.1093/nar/gkx1007 PubMed 29106617
