Rab5-L38R-mCherry
(Plasmid #102785)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 102785 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    EGFP-C1
  • Backbone size w/o insert (bp) 4731
  • Total vector size (bp) 5400
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    Rab5a
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    648
  • Mutation
    Leucine 38 changed to Arginine
  • GenBank ID
    NM_004162.4
  • Entrez Gene
    RAB5A (a.k.a. RAB5)
  • Promoter CMV
  • Tag / Fusion Protein
    • mCherry (N terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site EcoR1 (unknown if destroyed)
  • 3′ cloning site Sal1 (unknown if destroyed)
  • 5′ sequencing primer EGFP-C . CATGGTCCTGCTGGAGTTCGTG
  • 3′ sequencing primer SV40pA-R GAAATTTGTGATGCTATTGC
  • (Common Sequencing Primers)

Terms and Licenses

Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

mCherry-C2-Rab5a encodes wild-type human Rab5a,(NM_004162) as a fusion protein with mCherry. Rab5a was inserted between the Eco R1 and Sal 1 restriction sites. mCherry-C2 encodes a monomeric variant of DsRed. The backbone plasmid is pEGFP-C1 (Clontech). The C2 version of mCherry was created by insertion of a short piece of DNA between Xho 1 and EcoR1 restriction sites. In the resulting multiple cloning site, the Sac 1 restriction site has been eliminated and the Eco R1 restriction site is in frame.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    Rab5-L38R-mCherry was a gift from Donna Webb (Addgene plasmid # 102785 ; http://n2t.net/addgene:102785 ; RRID:Addgene_102785)
