pGL4-UPRE-luc2P-Hygro
(Plasmid #101788)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 101788 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pGL4.29
  • Backbone manufacturer
    Promega
  • Vector type
    Mammalian Expression, Luciferase
  • Selectable markers
    Hygromycin

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    3xUPRE
  • Species
    Synthetic
  • Insert Size (bp)
    87
  • Promoter minimal TATA-box promoter with low basal activity
  • Tag / Fusion Protein
    • Luciferase (C terminal on backbone)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site NheI (not destroyed)
  • 3′ cloning site BglII (not destroyed)
  • 5′ sequencing primer ctaactggccggtacctgag
  • 3′ sequencing primer aacagtaccggattgccaag
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pGL4-UPRE-luc2P-Hygro was a gift from Seiichi Oyadomari (Addgene plasmid # 101788 ; http://n2t.net/addgene:101788 ; RRID:Addgene_101788)

  • For your References section:

    Dkk3/REIC, an N-glycosylated Protein, Is a Physiological Endoplasmic Reticulum Stress Inducer in the Mouse Adrenal Gland. Fujita H, Bando T, Oyadomari S, Ochiai K, Watanabe M, Kumon H, Ohuchi H. Acta Med Okayama. 2020 Jun;74(3):199-208. doi: 10.18926/AMO/59950. 10.18926/AMO/59950 PubMed 32577017
