sg2.0 (PP7) Locus#2
(Plasmid #101155)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 101155 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    pLenti
  • Total vector size (bp) 10000
  • Vector type
    Lentiviral, CRISPR
  • Selectable markers
    Zeocin

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    NEB Stable
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    Locus #2(tandem repeat)
  • gRNA/shRNA sequence
    GAGAGTTGAGTCTGTACTGT
  • Species
    H. sapiens (human)
  • Promoter hU6

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site BsmBI (destroyed during cloning)
  • 3′ cloning site BsmBI (destroyed during cloning)
  • 5′ sequencing primer GAG GGC CTA TTT CCC ATG ATT CCT TCA TAT
  • 3′ sequencing primer cctagaaggtccattagctgcaaagattcc
  • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    sg2.0 (PP7) Locus#2 was a gift from Mazhar Adli (Addgene plasmid # 101155 ; http://n2t.net/addgene:101155 ; RRID:Addgene_101155)
  • For your References section:

    Live cell imaging of low- and non-repetitive chromosome loci using CRISPR-Cas9. Qin P, Parlak M, Kuscu C, Bandaria J, Mir M, Szlachta K, Singh R, Darzacq X, Yildiz A, Adli M. Nat Commun. 2017 Mar 14;8:14725. doi: 10.1038/ncomms14725. 10.1038/ncomms14725 PubMed 28290446
