pVEGFR2_TEV(N)_NES_TCS(Q'L)_FKBP_HA-dCas9(N)_P2A_Puro-WPRE
(Plasmid #101106)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 101106 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pVEGFR2_TEV(N)_NES_TCS(Q'L)_HA-dCas9(N)_P2A_Puro-WPRE
  • Modifications to backbone
    The rapamycin inducible hetero-dimerization FK506 binding protein 12 (FKBP) from pX856 vector (gift from Feng Zhang, Addgene plasmid #62888) was fused to the Nterminus of HA-dCas9(N) in pVEGFR2_TEV(N)_NES_TCS(Q'L)_HA-dCas9(N)_P2A_Puro-WPRE.
  • Vector type
    Mammalian Expression, CRISPR, Synthetic Biology
  • Selectable markers
    Puromycin

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    VEGFR2-FKBP-dCas9(N)
  • Tag / Fusion Protein
    • HA

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pVEGFR2_TEV(N)_NES_TCS(Q'L)_FKBP_HA-dCas9(N)_P2A_Puro-WPRE was a gift from Tudor Fulga (Addgene plasmid # 101106 ; http://n2t.net/addgene:101106 ; RRID:Addgene_101106)

  • For your References section:

    Engineering Synthetic Signaling Pathways with Programmable dCas9-Based Chimeric Receptors. Baeumler TA, Ahmed AA, Fulga TA. Cell Rep. 2017 Sep 12;20(11):2639-2653. doi: 10.1016/j.celrep.2017.08.044. 10.1016/j.celrep.2017.08.044 PubMed 28903044
