pGEX4T-1-Nix-S212D
(Plasmid #100761)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 100761 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pGEX
  • Backbone manufacturer
    GE Healthcare Life Sciences
  • Backbone size w/o insert (bp) 4900
  • Vector type
    Bacterial Expression
  • Selectable markers
    Plasmid confers resistance to 100 _g/ml ampicillin

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    30°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    GST-Nix-S212D
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    660
  • Mutation
    S212D
  • Entrez Gene
    BNIP3L (a.k.a. BNIP3a, NIP3L, NIX)
  • Promoter tac
  • Tag / Fusion Protein
    • GST (N terminal on backbone)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site EcoRI (not destroyed)
  • 3′ cloning site XhoI (not destroyed)
  • 5′ sequencing primer pGEX 5'
  • 3′ sequencing primer pGEX 3'
    • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

Use E. coli LB21 for expression

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pGEX4T-1-Nix-S212D was a gift from Joseph Gordon (Addgene plasmid # 100761 ; http://n2t.net/addgene:100761 ; RRID:Addgene_100761)
