pLentiCas9-BFP
(Plasmid #78545)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 78545 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    Lenti-Cas9-blast
  • Backbone manufacturer
    Addgene 52962
  • Backbone size w/o insert (bp) 12859
  • Total vector size (bp) 13561
  • Modifications to backbone
    Added BFP
  • Vector type
    Mammalian Expression, Lentiviral
  • Selectable markers
    Blasticidin

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    NEB Stable
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    BFP
  • Insert Size (bp)
    696
  • Promoter Fusion protein with Cas9

Cloning Information

  • Cloning method Gibson Cloning
  • 5′ sequencing primer CTGGACGCCACCCTGATCC
  • 3′ sequencing primer Gacgctgtagtcttcagagatg
  • (Common Sequencing Primers)

Resource Information

Terms and Licenses

Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pLentiCas9-BFP was a gift from Roderic Guigo & Rory Johnson (Addgene plasmid # 78545 ; http://n2t.net/addgene:78545 ; RRID:Addgene_78545)
  • For your References section:

    Scalable Design of Paired CRISPR Guide RNAs for Genomic Deletion. Pulido-Quetglas C, Aparicio-Prat E, Arnan C, Polidori T, Hermoso T, Palumbo E, Ponomarenko J, Guigo R, Johnson R. PLoS Comput Biol. 2017 Mar 2;13(3):e1005341. doi: 10.1371/journal.pcbi.1005341. eCollection 2017 Mar. PCOMPBIOL-D-16-01254 [pii] PubMed 28253259
