pD10AH840AhCas9 (GB1041)
(Plasmid
#68207)
-
PurposeProvides the human codon optimized CDS of Cas9 protein with mutated (D10A, H840A) and inactivated catalytic domains as a level 0 GoldenBraid part
-
Depositing Lab
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 68207 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepUPD
-
Backbone manufacturerself-made; derived from pGEMT-Easy manufactured by Promega
-
Vector typeCRISPR, Synthetic Biology
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert nameCas9 coding region with mutated (D10A, H840A) and inactivated catalytic domains (human codon optimised)
-
Insert Size (bp)4137
-
MutationBsaI and BsmBI sites removed; human codon optimised; mutated (D10A, H840A) and inactivated catalytic domains
Cloning Information
- Cloning method Restriction Enzyme
- 5′ cloning site BsmBI (destroyed during cloning)
- 3′ cloning site BsmBI (destroyed during cloning)
- 5′ sequencing primer T7
- 3′ sequencing primer SP6 (Common Sequencing Primers)
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
Depositor Comments
insert can be released with BsaI
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pD10AH840AhCas9 (GB1041) was a gift from Diego Orzaez (Addgene plasmid # 68207 ; http://n2t.net/addgene:68207 ; RRID:Addgene_68207) -
For your References section:
GoldenBraid 2.0: a comprehensive DNA assembly framework for plant synthetic biology. Sarrion-Perdigones A, Vazquez-Vilar M, Palaci J, Castelijns B, Forment J, Ziarsolo P, Blanca J, Granell A, Orzaez D. Plant Physiol. 2013 Jul;162(3):1618-31. 10.1104/pp.113.217661 PubMed 23669743
