pBbA5k-EPL48
(Plasmid
#45414)
-
Depositing Lab
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 45414 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepBbA5k
-
Vector typeSynthetic Biology
Growth in Bacteria
-
Bacterial Resistance(s)Kanamycin, 50 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH1 with AcrAB knocked out
-
Copy numberLow Copy
Gene/Insert
-
Gene/Insert namePFL_1158
-
SpeciesSynthetic
-
Insert Size (bp)4152
- Promoter LacUV5
-
Tag
/ Fusion Protein
- His (C terminal on insert)
Cloning Information
- Cloning method Ligation Independent Cloning
- 5′ sequencing primer CAA AAG ATC TTT TAA GAA GGA GAT ATA CAT ATG TTC CGC TAT GCC TTG CC
- 3′ sequencing primer CAG TGG TGA TGG TGA TGA TGG GTT TTC TTG ACC CTG AAC CAG G (Common Sequencing Primers)
Resource Information
-
A portion of this plasmid was derived from a plasmid made byATCC BAA-477D
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
Depositor Comments
Please note that this plasmid may require a unique bacterial strain, so make sure to confirm that you can also obtain the appropriate growth strain. Please contact us at [email protected] or contact our distributors if you have any questions.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pBbA5k-EPL48 was a gift from Aindrila Mukhopadhyay (Addgene plasmid # 45414 ; http://n2t.net/addgene:45414 ; RRID:Addgene_45414) -
For your References section:
Engineering microbial biofuel tolerance and export using efflux pumps. Dunlop MJ, Dossani ZY, Szmidt HL, Chu HC, Lee TS, Keasling JD, Hadi MZ, Mukhopadhyay A. Mol Syst Biol. 2011 May 10;7:487. doi: 10.1038/msb.2011.21. 10.1038/msb.2011.21 PubMed 21556065
