pGDP3 aph(9)-Ia
(Plasmid #112882)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 112882 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    pBR322
  • Vector type
    Bacterial Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Low Copy

Gene/Insert

  • Gene/Insert name
    aph(9)-Ia
  • Species
    Legionella pneumophila
  • Promoter Pbla
  • Tags / Fusion Proteins
    • 6xHis (C terminal on backbone)
    • 6xHis (N terminal on backbone)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site NdeI (not destroyed)
  • 3′ cloning site XhoI (not destroyed)
  • 5′ sequencing primer CATGAGACAATAACCCTG
  • 3′ sequencing primer CCAACTCAGCTTCCTTTC
  • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

JoVE antibiotic dereplication paper: Zubyk, H.L., Cox, G., Wright, G.D. Antibiotic Dereplication Using the Antibiotic Resistance Platform. J. Vis. Exp. (152), e60536, doi:10.3791/60536 (2019). (https://www.jove.com/video/60536/antibiotic-dereplication-using-the-antibiotic-resistance-platform)

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pGDP3 aph(9)-Ia was a gift from Gerard Wright (Addgene plasmid # 112882 ; http://n2t.net/addgene:112882 ; RRID:Addgene_112882)
  • For your References section:

    A Common Platform for Antibiotic Dereplication and Adjuvant Discovery. Cox G, Sieron A, King AM, De Pascale G, Pawlowski AC, Koteva K, Wright GD. Cell Chem Biol. 2017 Jan 19;24(1):98-109. doi: 10.1016/j.chembiol.2016.11.011. Epub 2016 Dec 22. 10.1016/j.chembiol.2016.11.011 PubMed 28017602
