pMM532
(Plasmid #112529)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 112529 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    pZA1
  • Backbone size w/o insert (bp) 2305
  • Total vector size (bp) 2875
  • Modifications to backbone
    ProD promoter; T1 terminator
  • Vector type
    Bacterial Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    HrtR
  • Species
    Lactococcus lactis
  • Insert Size (bp)
    570
  • Promoter ProD

Cloning Information

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pMM532 was a gift from Timothy Lu (Addgene plasmid # 112529 ; http://n2t.net/addgene:112529 ; RRID:Addgene_112529)
  • For your References section:

    An ingestible bacterial-electronic system to monitor gastrointestinal health. Mimee M, Nadeau P, Hayward A, Carim S, Flanagan S, Jerger L, Collins J, McDonnell S, Swartwout R, Citorik RJ, Bulovic V, Langer R, Traverso G, Chandrakasan AP, Lu TK. Science. 2018 May 25;360(6391):915-918. doi: 10.1126/science.aas9315. 10.1126/science.aas9315 PubMed 29798884
